Elle TENS (Maternity TENS Machine)

£71.50 (Exc VAT)
Quantity:

Product Description

The Elle TENS is so easy to use. All the settings are pre-set so there is no fuss in setting up. The Elle TENS uses the latest Opti-Max technology.

What is Optimax? An extra pulse of pain combatting power, often used in the final stages of labour - when you most need it. Optimax is a feature of both the Elle TENS and Elle TENS+

Elle TENS Awards

Features and Benefits

  • Pre set modes for ease of use
  • Integrated boost button
  • Optimax technology for extra power
  • Uses 4 large pads
  • Easy to read user display
  • Neck cord for mobility
  • Can be used for post natal pain

What's Included?

  • Pack of 4 electrode pads
  • Instructions
  • 2 leadwires plus 1 spare
  • 2 x AA batteries plus 2 spare
  • Neck cord
  • Soft carrying pouch
  • Women's Guide to Drug Free Pain Relief - FREE


Downloads

Elle TENS Manual
Elle TENS

Instructions for use.

Download PDF

(567kb)

BabycareTENS.com TENS Hire Specialists Prefer to hire the Elle TENS, visit:
BabycareTENS.com - TENS machine hire specialists



Technical details

Equipment type Dual Channel Digital TENS
Display Digital LCD - 5 seven segment digits around 42 segments
Modes 2 burst modes and 2 boost modes
  Pulse Frequency (Hz) Pulse Width (µs) Description
Burst 1 16 150* 1 burst per second, 8 pulses per burst
Burst 2 32 150* 2 bursts per second, 8 pulses per burst
Boost 1 80 150* Continuous
Boost 2 100 150* Continuous
  * Default pulse width after mode changed (pulse width is NOT changed when switched between BURST and BOOST mode)
5 selectable pulse widths in all modes: 50, 100, 150, 200, 250
Automatic Power Off The Elle TENS will switch off after 5 minutes if not used
Output Voltage 0 - 55v zero to peak adjustable in 15 steps at 500 Ω load
Output Intensity 0 - 110mA adjustable in 15 steps at 500 Ω load Intensity level will drop back to zero after programme changes
Output Waveform Symmetrical bi-phasic rectangular
Output Jacks CE Touch-proof jacks
Battery 2 x 1.5v AA Battery (Type LR6)
Unit Size 115mm x 55mm x 30mm
Unit Weight 75 grams
Low Battery Indicator 2.2v±0.2v
Classification This unit is fully compliant with EEC Directive 93/42/EEC, classified as internally powered equipment type BF. It is intended for continuous operation.
